Overview​

'Initiate Deduction' is the core step of the Subscription feature. Once a user completes the initial payment authorization (i.e., a QuickPay ID is successfully generated), the merchant can use this API to automatically charge the user’s original payment method on the agreed schedule, without requiring the user to re-enter card details or confirm the payment.

Flow Chart​

How It Works​

  1. The merchant server calls the Direct API mode and submits the required parameters, where the quickpay_id parameter represents the card information token.
cURL -X POST 'https://test-secure.oceanpayment.com/gateway/direct/pay'
-H 'Content-Type: application/x-www-form-urlencoded' \
-d 'account=995149' \
-d 'terminal=99514901' \
-d 'signValue=6b86b273ff34fce19d6b804eff5a3f5747ada4eaa22f1d49c01e52ddb7875b4b' \
-d 'quickpay_id=9ead3654-8f84-4d02-acab-6ac9dd10531f' \
-d 'backUrl=https://www.abc.com/back.php' \
-d 'noticeUrl=https://www.abc.com/notice.php' \
-d 'order_number=NO12345678' \
-d 'order_currency=USD' \
-d 'order_amount=0.01' \
-d 'methods={methods}' \
-d 'order_notes=' \
-d 'service_mode=Y1' \
-d 'billing_firstName=test' \
-d 'billing_lastName=test' \
-d 'billing_email=test@gmail.com' \
-d 'billing_phone=13800138000' \
-d 'billing_country=US' \
-d 'billing_state=AL' \
-d 'billing_city=Washington D.C.' \
-d 'billing_address=705A big Road' \
-d 'billing_zip=529012' \
-d 'billing_ip=127.0.0.1' \
-d 'productNum=1' \
-d 'productName=Red Dress' \
-d 'productSku=#001' \
-d 'productPrice=0.01' \

Business Mode​

Note

In recurring payment scenarios, the service_mode field is critical and required. It is used to identify the role in the current subscription flow (e.g., first-time purchase, renewal) and the subscription cycle type (e.g., monthly, yearly).

  • The service_mode parameter should be set according to the following scenarios:
TypePeriodservice_mode
Single Purchase-S1
First-time PurchaseWeeklyW1
MonthlyM1
QuarterlyQ1
Semi-AnnualH1
AnnualY1
First Automatic RenewalWeeklyW2
MonthlyM2
QuarterlyQ2
Semi-AnnualH2
AnnualY2
Subsequent Automatic Renewal (second or more)WeeklyW3
MonthlyM3
QuarterlyQ3
Semi-AnnualH3
AnnualY3
  • Example of values
-d 'service_mode = Y1' \

Processing the Response​

  1. In the returned parameters：
  • Single or first-time purchase：the xml->pay_url field is empty. There is no 3D authentication step, so the xml itself is the payment result. Asynchronous notification via noticeUrl is also triggered.
  • Renewal：the xml->pay_url field is not empty. A 3D authentication step is required. The user must be redirected to pay_url to complete 3D verification. The payment result will then be sent again to backUrl, by default via $_POST. Asynchronous notification via noticeUrl is also triggered.
<?xml version="1.0" encoding="UTF-8"?>
<response>
    <notice_type>transaction</notice_type>
    <push_dateTime>2025-09-03 10:21:14</push_dateTime>
    <account>995149</account>
    <terminal>99514901</terminal>
    <signValue>924347D8E9C9BAC2EC91449C70540FF49E0DD5711F03E8A871DCA34CED023AB6</signValue>
    <methods>Credit Card</methods>
    <order_number>JSCSE-3128790866</order_number>
    <card_country>PL</card_country>
    <order_currency>USD</order_currency>
    <order_amount>0.01</order_amount>
    <order_notes></order_notes>
    <card_number>411111***1111</card_number>
    <card_type>Visa</card_type>
    <payment_country></payment_country>
    <payment_id>250902111334242179639</payment_id>
    <payment_authType>2</payment_authType>
    <payment_status>-1</payment_status>
    <payment_details>80093:3D Authorized Service not completed</payment_details>
    <payment_solutions></payment_solutions>
    <payment_risk></payment_risk>
    <payment_amount></payment_amount>
    <payment_exchangeRate></payment_exchangeRate>
    <auth_reason></auth_reason>
    <auth_code></auth_code>
    <pay_userId></pay_userId>
    <pay_url>https://secure.oceanpayment.com:443/gateway/direct/redirect?pay_id=af5e28ee57061f4fd1dd307a7bc56c7289d9041d0b5494195d91b7c5166b6e30</pay_url>
</response>
  • The merchant redirects the user to the pay_url.：
HTTP/1.2 301 Moved Permanently
Location: {pay_url}
  1. Check the payment status as explained, and you should also use noticeUrl to receive asynchronous transaction notifications.

Signature​

See Signature and Verification for details on request signing and response validation.

API Reference​

👉Explore our to continue your integration.
